CSZ CLIMATIC TEMPERATURE TEST CHAMBER

  • Mechanically air cooled cascade
  • 200 kg
  • Watlow CSZ F4 controller
  • All hire chambers are calibrated to NPL
  • Brochure (PDF)
Ref. No. 1024
Internal Dimensions 400 x 280 x 300mm (WxDxH)
External Dimensions 1200 x 1000 x 900mm (WxDxH)
Temperature Range -70°C to +190°C
Rate of Change 2.5°C/min from +24°C to -40°C
2.2°C/min from +24°C to -54°C
1.5°C/min from +24°C to -68°C
7°C/min from +24°C to +94°C
4°C/min from +24°C to +190°C
5.8°C/min from -34°C to +24°C
6.1°C/min from -68°C to +24°C
Power Supply 230V / 1 phase / 16 Amps
Port Holes 1 x 50mm dia Left Hand Side
Humidity Range 10% to 98% RH
