ATT CLIMATIC TEMPERATURE CHAMBER

  • Mechanically air cooled cascade
  • 990 kg
  • Programmable Logic controller
  • All hire chambers are calibrated to NPL
  • Brochure (PDF)
Ref. No. 1015
Internal Dimensions 850 x 730 x 892mm (WxDxH)
External Dimensions 1124 x 1768 x 2049mm (WxDxH)
Temperature Range -75°C to +180°C
Rate of Change 4.5°C/min Heating from -70°C to +180°C
4.0°C/min Cooling from +180°C to -70°C
Power Supply 400V / 3 phase / 32 Amps + N + E
Port Holes 1 x 80mm dia Left Hand Side
1 x 150mm dia Right Hand Side
Humidity Range 10% to 98% RH in the range +10°C to +95°C
